Ceiling Fan Wiring Diagram 4 Wires

Here's a basic wiring diagram for a ceiling fan with 4 wires: https://fanairdesire.com/ceiling-fan-wiring-diagram-4-wire/ 1. **Wire Colors:** - Black: wire for fan motor - Blue: wire for light kit (if applicable) - White: Neutral wire - Green or bare copper: Ground wire 2. **Connections:** - Connect the black wire from the ceiling fan to the black wire from the ceiling outlet or junction box. This is the wire for the fan motor. - If your ceiling fan has a light kit, connect the blue wire from the fan to the black wire from the ceiling outlet or junction box that controls the light. - Connect the white wire from the ceiling fan to the white wire from the ceiling outlet or junction box. This is the neutral wire. - Connect the green or bare copper wire from the ceiling fan to the green or bare copper wire from the ceiling outlet or junction box. This is the ground wire. 3. **Mounting:** - Follow the manufacturer's instructions to mount the ceiling fan securely to the ceiling, ensuring that the mounting bracket is properly installed and the fan is balanced. 4. **Switches:** - Use a double wall switch or a remote control to independently control the fan and light functions, if desired. - If using a single wall switch, the fan and light will be controlled together. Use the pull chains on the fan to control the fan speed and light settings. 5. **Testing:** - Once all connections are made, turn on the power and test the fan and light to ensure they are functioning properly. - If the fan or light does not work, double-check your connections and make sure they are secure. It's important to follow all local electrical codes and regulations when wiring a ceiling fan. If you're unsure about any aspect of the installation, it's recommended to consult a licensed electrician for assistance.
